AVADA Terreno Pole-top luminaires with different light distributions.
Luminaires in four sizes and with different light outputs:
• with asymmetrical light distribution for providing spatial illumination of surfaces, squares and parking spaces, or
• with asymmetrical flat beam light distribution for providing illumination of driveways and streets, or
• with asymmetrical light distribution for illuminating playing fields from a great height
Using the adjustable attack angle of the luminaire housing, the light distribution can be adjusted exactly to the surface to be illuminated.
Pole-top luminaires, ready for installation, for single and double configuration.
Download Product Leaflet >
Mounting heights 4000 – 11000 mm
Protection class IP 66
Cast aluminium, aluminium and stainless steel
Tempered Safety glass
Optional : dimmable 1-10 V
Wattage 60~90 watt
Luminous Flux 7000 ~ 10800 lm
Attack angle adjustable in steps 0° to 15° +/-
You can find luminaires for operating with alternating
and direct current in the table under AC .
LED colour temperature optionally 4000 K or 3000 K
4000 K
3000 K
Luminaire colour optionally graphite or silver
Graphite
Grey
.
